Image Gallery
Left Click while zoom
SpecificationPrevious Page |
||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Model Name | N-36TM | |||||||||||
| Description | SAS III / SATA III Hot Swap Module | |||||||||||
| Number of HDD | 3 * 3.5" or 2.5" SAS / SATA | |||||||||||
| Color | Black | |||||||||||
| RAID Functions | Supported if RAID card is installed | |||||||||||
| Material | Alluminium | |||||||||||
| Cooling Fan | 7 cm fan with adjustable speed | |||||||||||
| LED Indicator | Power On - Blue HDD Access - Purple Blinking |
|||||||||||
| Security Design | Metal Key Lock | |||||||||||
| Fan Failure Sensor | Available | |||||||||||
| Fits In | 2 contiguous optical drive (5.25" external) bays | |||||||||||
| Ext. Connectors | 3 * SAS III / SATA II / SATA III | |||||||||||
| HDD Connection | Cableless | |||||||||||
| Weight | 1.1 KG | |||||||||||
| Download PDF File | ||||||||||||
