RR-2644X4 - Controller

Specification Previous Page
Features
Host Adapter Architecture		Operating System Support
	PCI-Express x4		Microsoft Windows 2008/2003/XP/2000/X64 Edition/Vista 32 and 64 bit
	1 External Mini-SAS port		Linux (Fedora Core, Red Hat Enterprise / CentOS, SuSE)
	Upto 4 SAS/SATA Hard Drives		Mac OS X 10.4.x and above
	NCQ (Native Command Queuing)		Free BSD
	Low Profile		Linux Open Source
Advanced RAID Features		Package Contents
	Support RAID 0,1,5,10 and JBOD		Controller Card
	Multiple RAID support		User's Guide
	Multiple logical drive support		Software CD with Drivers and Manual
	BIOS booting support		Low profile bracker
	Online Array roaming	Operating Voltage
	Automatic drive (insert/remove) detection		PCI-e: 3.3V / Power; 5W
	Automatic RAID rebuild
	64bit LBA support greater than 2TB per volume
	S.M.A.R.T (Early Warning System)
	TerabyteGuard for data protection and reliability
	Bad sector repair and remapping to reduce dropped drives
Array Monitors, Alerts and Indicators
	Hard Drive LED Indicators (Activity and Failed)
	Email Notification
	Alarm/Buzzer alerts for drive/array failure
	Enclosure Management support with I2C and SGPIO
RAID Management
	Online Capacity Expansion (OCE)
	Online RAID Level Migration (OLRM)
	Quick and Background initialization for instant RAID configuration
	Write Back and Write Through support
	API library for customization
	CLI (Command Line Interface)
	Web GUI RAID management (local and remote monitoring)
	SHI (Drive analysis driven from S.M.A.R.T)
